Bindy Scout¶

Two Deployment Modes

Same-cluster mode (default): Scout and the Bindy operator run in the same cluster. No extra configuration needed.

Remote cluster mode: Scout runs on a workload cluster and writes to a dedicated Bindy cluster elsewhere. Set BINDY_SCOUT_REMOTE_SECRET to a Secret containing a kubeconfig for the Bindy cluster. Scout will create ARecords and validate zones there while watching local Ingresses and Services.

The Scout Bee¶

In a honeybee colony, scout bees are the advance team. While the main workers tend the hive, a small number of scouts venture out into the surrounding terrain, find promising flower patches, return to the hive, and communicate their discoveries through the waggle dance — a precise, information-rich signal that tells their sisters exactly where the nectar is.

Bindy Scout plays the same role in your Kubernetes infrastructure.

The main bindy run process is the hive — it manages BIND9 DNS infrastructure and reconciles DNS zones and records from their canonical CRD definitions. But it doesn't know about every application that flies around your cluster. That's where Scout comes in.

Scout is a lightweight, event-driven controller that ventures into your workload namespaces, watches Ingress and LoadBalancer Service resources, and — when it finds one annotated with the right signal — carries that DNS information back to the bindy cluster and registers an ARecord on the application's behalf.

The application team annotates their Ingress or Service. Scout finds it, validates it, derives the correct record name from the DNS zone, and server-side applies the ARecord CR in the bindy namespace. From there, the normal ARecord reconciler picks it up and programs BIND9. The application never needs to know how DNS works — it just raises a flag and Scout handles the rest.

What Scout Solves¶

In a multi-team platform, the DNS operator and the application teams live in different worlds:

The platform team owns the bindy-system namespace, the DNSZone CRs, and the BIND9 instances.
Application teams own their own namespaces, Deployment objects, and Ingress resources.

Bridging this gap traditionally requires either:

Manual DNS record management (error-prone, doesn't scale), or
Granting application teams write access to the bindy-system namespace (violates least-privilege).

Scout eliminates both compromises. Application teams annotate their own Ingresses — resources they already own — and Scout does the translation work. No cross-namespace write access required on the application side.

How It Works¶

sequenceDiagram participant App as Application Team participant Source as Ingress or Service participant Scout as Bindy Scout participant ARecord as ARecord CR participant Bindy as Bindy Operator participant BIND9 as BIND9 DNS App->>Source: Annotate with bindy.firestoned.io/scout-enabled: "true" Source->>Scout: Watch event (kube-rs Controller) Scout->>Scout: Validate annotations + derive record name + resolve IP Scout->>ARecord: Server-side apply (bindy-system namespace) ARecord->>Bindy: Watch event triggers ARecord reconciler Bindy->>BIND9: Program A record via RNDC

Scout watches all Ingress and LoadBalancer Service resources cluster-wide (excluding its own namespace and any configured exclusions).
When a watch event fires, Scout checks for the bindy.firestoned.io/scout-enabled: "true" annotation.
If enabled, Scout reads the zone annotation, derives the DNS record name, and resolves the IP — from the LoadBalancer status or an explicit annotation override.
Ingress: record name derived by stripping the zone suffix from each rule host (e.g. app.example.com in zone example.com → app). One ARecord per rule host.
Service: record name is the Service name. Exactly one ARecord per Service.
Scout server-side applies an ARecord CR in the configured target namespace (default: bindy-system), stamped with labels identifying the source cluster, namespace, and resource.
The main bindy operator's ARecord reconciler picks up the new CR and programs BIND9.

Quick Start¶

1. Annotate your Ingress or Service¶

Minimal — when Scout is configured with --default-zone and --default-ips:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: my-app
  namespace: my-app-ns
  annotations:
    bindy.firestoned.io/scout-enabled: "true"
spec:
  rules:
    - host: my-app.example.com
      ...

With overrides — per-Ingress zone and IP take precedence over Scout defaults:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: my-app
  namespace: my-app-ns
  annotations:
    bindy.firestoned.io/scout-enabled: "true"
    # Override the default zone for this Ingress (optional when --default-zone is set)
    bindy.firestoned.io/zone: "example.com"
    # Optional: explicit IP override (overrides --default-ips and LB status)
    # bindy.firestoned.io/ip: "10.0.1.42"
    # Optional: TTL override in seconds (defaults to zone TTL)
    # bindy.firestoned.io/ttl: "300"
spec:
  rules:
    - host: my-app.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: my-app
                port:
                  number: 80

Scout will create an ARecord named scout-<cluster>-my-app-example-com-<hash> in the bindy-system namespace (see Record names), with:

spec.name: my-app (derived by stripping the zone suffix from the host)
spec.ipv4Addresses: every IPv4 address in the Ingress LoadBalancer status
Labels: bindy.firestoned.io/managed-by, source-cluster, zone, and one contributor label for the Ingress
Annotation bindy.firestoned.io/scout-contributors: the Ingress and the addresses it resolved

For a LoadBalancer Service:

apiVersion: v1
kind: Service
metadata:
  name: my-grpc-api
  namespace: my-app-ns
  annotations:
    bindy.firestoned.io/scout-enabled: "true"
    bindy.firestoned.io/zone: "example.com"
spec:
  type: LoadBalancer
  selector:
    app: my-grpc-api
  ports:
    - port: 9090
      targetPort: 9090

Scout will create an ARecord named scout-<cluster>-my-grpc-api-example-com-<hash> in the bindy-system namespace, resolving to my-grpc-api.example.com.

2. Deploy Scout¶

apiVersion: apps/v1
kind: Deployment
metadata:
  name: bindy-scout
  namespace: bindy-system
spec:
  replicas: 1
  strategy:
    type: Recreate   # never two Scouts at once, see "Upgrading Scout" below
  selector:
    matchLabels:
      app: bindy-scout
  template:
    metadata:
      labels:
        app: bindy-scout
    spec:
      serviceAccountName: bindy-scout
      containers:
        - name: scout
          image: ghcr.io/firestoned/bindy:latest
          args: ["scout", "--cluster-name", "prod"]
          env:
            - name: BINDY_SCOUT_NAMESPACE
              value: "bindy-system"
            - name: POD_NAMESPACE
              valueFrom:
                fieldRef:
                  fieldPath: metadata.namespace
            - name: RUST_LOG
              value: "info"
            - name: RUST_LOG_FORMAT
              value: "json"

Annotations Reference¶

These annotations apply to both Ingress and LoadBalancer Service resources.

Annotation	Required	Description
`bindy.firestoned.io/scout-enabled`	Yes (preferred)	Set to `"true"` to opt this Ingress or Service into Scout management. The record kind always defaults to `ARecord`.
`bindy.firestoned.io/recordKind`	(legacy, Ingress only)	Accepted for backward compatibility. `"ARecord"` opts in. Prefer `scout-enabled: "true"` for new deployments.
`bindy.firestoned.io/zone`	Yes (unless `--default-zone` is set)	The DNS zone for this resource (e.g. `example.com`). Overrides the operator's `--default-zone`. For Ingress: hosts outside the zone are skipped with a warning.
`bindy.firestoned.io/ip`	No	Explicit IP address(es) for the A record. Accepts a single IP (`"10.0.0.1"`) or a comma-separated list (`"10.0.0.1,10.0.0.2,10.0.0.3"`): every entry becomes one address on the resulting `ARecord` (the record lists its addresses sorted numerically, each once). Whitespace around each entry is trimmed and empty entries are skipped. When set, overrides both `--default-ips` and the LoadBalancer status IP.
`bindy.firestoned.io/ttl`	No	TTL override in seconds, a positive integer. When absent, the created `ARecord` inherits the TTL from the `DNSZone` spec. A value that is not a positive integer (`"abc"`, `"0"`, `"-5"`, `"1.5"`) is an error: Scout logs a warning, publishes nothing for that resource, and retries every 30s until the annotation is fixed. Records it already published are left as they are.
`bindy.firestoned.io/record-name`	No	Override the `spec.name` of the created `ARecord`. When set, replaces the name normally derived by stripping the zone suffix from the host. Use `"@"` for the zone apex. On multi-host resources (`Ingress`, `HTTPRoute`, `TLSRoute`) the override applies to every host, so all of them publish that one name and the resource adds its addresses to it once. An override that is not a legal DNS name is treated like an invalid TTL: a warning, nothing published for that resource, a retry, and existing records left in place.

Scout only writes IPv4 addresses (ARecord is IPv4-only). An address read from a status field (an Ingress or Service status.loadBalancer, or a Gateway's status.addresses) that is not IPv4 is skipped with a warning. Every IPv4 address in a load balancer status is published, in status order and each address once: a LoadBalancer Service with three ingress IPs gets one ARecord with three addresses. Several resources that publish the same name share one ARecord: see Several resources publishing one name.

Zone authorization (cross-namespace)¶

Scout only publishes into a zone that authorizes the source object's namespace. This prevents a tenant in one namespace from creating records in another tenant's zone (a cross-tenant DNS-hijack / confused-deputy risk, since Scout writes with a cluster-privileged client).

A source object (Ingress/Service/HTTPRoute/GRPCRoute/TLSRoute/TCPRoute) may publish into a zone when either:

the matching DNSZone lives in the same namespace as the source object, or
the DNSZone carries bindy.firestoned.io/allow-zone-namespaces listing the source namespace (comma-separated), or the * wildcard.

apiVersion: bindy.firestoned.io/v1beta1
kind: DNSZone
metadata:
  name: example-com
  namespace: bindy-system
  annotations:
    bindy.firestoned.io/allow-zone-namespaces: "tenant-a,tenant-b"   # or "*"
spec:
  zoneName: example.com

If a source object names a zone that does not authorize its namespace, Scout skips it and logs ... namespace not authorized for zone .... This mirrors the same annotation gate the DNSZone reconciler enforces for cross-namespace instance targeting. See the Migration Guide for upgrade steps.

Publishing limits for this cluster (`--allowed-zones`, `--allowed-ip-ranges`)¶

The zone grant above is checked per namespace. Namespace names are not unique across clusters, so a grant written for team-a on one cluster also covers a team-a namespace on every other cluster feeding the same bindy cluster. Two settings let whoever deploys Scout bound what this cluster can publish, whatever its tenants write in their annotations (ADR-0025):

Setting Effect

--allowed-zones / BINDY_SCOUT_ALLOWED_ZONES Comma-separated zones. An entry allows the zone and its subzones: foo.example.com allows foo.example.com and api.foo.example.com, not bar.example.com or badfoo.example.com. A source whose zone is outside the list publishes nothing; Scout logs a warning and waits for the source to change. Records it published earlier stay, so an allowlist typo never takes names off the air.

--allowed-ip-ranges / BINDY_SCOUT_ALLOWED_IP_RANGES Comma-separated IPv4 CIDR ranges (a bare address means /32). Every address a source would publish, from the bindy.firestoned.io/ip annotation, its own load-balancer status, or --default-ips, must fall in a range; otherwise the source publishes nothing and Scout retries every 30 seconds, since a discovered address can change without the source changing. A route's addresses discovered from its Gateway or the gateway Services are the exception: one outside the ranges is dropped with a warning and the route publishes the rest (ADR-0028, so a stray labelled Service cannot take a gateway class off the air).

Both are unset by default, which keeps the previous unrestricted behavior and logs a startup warning. Set them on every Scout that serves tenants:

bindy scout --cluster-name foo \
  --allowed-zones foo.example.com \
  --allowed-ip-ranges 10.20.0.0/24

These checks run inside Scout, so they stop careless or malicious tenants but not a compromised Scout or a stolen token. In multi-cluster mode, also bind the cluster's ServiceAccount on the bindy cluster: see Binding each cluster to its names and zones.

Watched Resources¶

Scout supports three categories of Kubernetes resources as DNS record sources.

1. Ingresses (Legacy)¶

Kubernetes Ingress is deprecated

The networking.k8s.io/v1 Ingress API is considered legacy in modern Kubernetes clusters. New deployments should prefer Gateway API (HTTPRoute / TLSRoute / TCPRoute) where available. Scout continues to support Ingress for backward compatibility.

Scout processes each rule in the Ingress spec independently. For a multi-host Ingress:

spec:
  rules:
    - host: api.example.com      # → ARecord "scout-prod-api-example-com-<hash>"  (name: "api")
    - host: www.example.com      # → ARecord "scout-prod-www-example-com-<hash>"  (name: "www")
    - host: other.io             # → skipped (not in zone "example.com")

The record name is derived by stripping the zone suffix from the host:

Host	Zone	Derived record name
`api.example.com`	`example.com`	`api`
`deep.sub.example.com`	`example.com`	`deep.sub`
`example.com`	`example.com`	`@` (apex record)
`other.io`	`example.com`	(skipped — not in zone)

Opt in with the bindy.firestoned.io/scout-enabled: "true" annotation. Each rule host publishes one DNS name, and each DNS name is one ARecord, named scout-{cluster}-{name}-{zone}-{hash} (see Record names). The IP is resolved from the bindy.firestoned.io/ip annotation, then --default-ips, then the Ingress LoadBalancer status.

When a host is removed from the Ingress, or stops matching the zone, Scout removes the Ingress's addresses from that name's ARecord on the next reconcile, and deletes the record if no other resource still publishes the name. The same applies to HTTPRoute, GRPCRoute, and TLSRoute hostnames.

2. Services (LoadBalancer)¶

Scout watches LoadBalancer Services and automatically creates ARecord CRs — no Ingress required. This covers gRPC, TCP, and other non-HTTP workloads exposed directly via a cloud load balancer.

Opt in with the same annotation:

apiVersion: v1
kind: Service
metadata:
  name: my-grpc-api
  namespace: my-app
  annotations:
    bindy.firestoned.io/scout-enabled: "true"
    bindy.firestoned.io/zone: "example.com"          # required if no --default-zone
    # bindy.firestoned.io/ip: "1.2.3.4"              # optional IP override
    # bindy.firestoned.io/ttl: "300"                  # optional TTL override
spec:
  type: LoadBalancer
  selector:
    app: my-grpc-api
  ports:
    - port: 443
      targetPort: 8443

Scout writes the ARecord named scout-{cluster}-{service-name}-{zone}-{hash}, with:

DNS record name: {service-name} (relative to the zone) → resolves to my-grpc-api.example.com
IP: from bindy.firestoned.io/ip annotation → --default-ips → every IPv4 status.loadBalancer.ingress[].ip

ClusterIP and NodePort services are skipped, because they have no routable external IP. If an opted-in LoadBalancer Service is changed to one of those types, Scout removes its addresses (deleting the ARecord when no other resource publishes the name) and removes its finalizer, just as when the opt-in annotation is removed.

If no external IP has been assigned yet, Scout logs a warning and re-queues after 30s:

WARN scout: service my-app/my-grpc-api has no external IP yet; requeueing in 30s

Comparison with Ingress:

	Ingress	Service
DNS names published	One per `rules[].host`	Exactly one
IP source	annotation, `--default-ips`, LB status	annotation, `--default-ips`, LB status
Contributor key	`Ingress/<namespace>/<name>`	`Service/<namespace>/<name>`

Find the records a resource contributes to through its contributor key in the bindy.firestoned.io/scout-contributors annotation (see Finding a resource's records).

3. Gateway API (HTTPRoute, GRPCRoute, TLSRoute, and TCPRoute)¶

Scout watches HTTPRoute, GRPCRoute, TLSRoute, and TCPRoute resources from the Gateway API, for each kind the cluster actually serves — see Gateway API detection. The same opt-in annotation (bindy.firestoned.io/scout-enabled: "true") and zone/IP/TTL annotations apply. For HTTPRoute, GRPCRoute, and TLSRoute, Scout creates one ARecord per hostname in spec.hostnames[]. TCPRoute has no spec.hostnames[] field — Scout creates a single ARecord using the name supplied by the bindy.firestoned.io/record-name annotation.

IP resolution follows the gateway chain

Gateway API routes have no LoadBalancer status of their own. When no bindy.firestoned.io/ip annotation is set, Scout follows the route's parentRefs to the serving Gateway and publishes the Gateway's status.addresses, or, when those are empty and the Gateway's class is in the operator-configured --gateway-service map, the addresses of the LoadBalancer Service(s) that map names. Routes re-resolve whenever their Gateway or one of those Services changes. This lets operators avoid making every route repeat an IP that is already discoverable from the gateway (e.g. Traefik's proxy Service). The full precedence is: bindy.firestoned.io/ip annotation, then the discovered gateway addresses, then --default-ips, then requeue. See Addresses from the Gateway.

See Gateway API Routes for the full reference, examples, record naming, labels, and RBAC requirements.

Labels and annotations on created ARecords¶

Scout writes one ARecord per DNS name, shared by every resource of this cluster that publishes that name (ADR-0026). Every such record carries these labels:

Label	Value
`bindy.firestoned.io/managed-by`	`scout`
`bindy.firestoned.io/source-cluster`	`<BINDY_SCOUT_CLUSTER_NAME>`
`bindy.firestoned.io/zone`	Zone name
`contributor.scout.bindy.firestoned.io/<hash>`	`true`, one label per contributing resource. `<hash>` is the first 16 hex characters of the SHA-256 of the resource's kind, namespace and name joined by NUL bytes

and the annotation bindy.firestoned.io/scout-contributors, a JSON map from each contributing resource (<kind>/<namespace>/<name>) to the addresses and TTL it resolved:

{
  "Service/kube-system/kube-api-a": {"ips": ["10.0.0.246"]},
  "Service/kube-system/kube-api-b": {"ips": ["10.0.0.241"], "ttl": 60}
}

spec.ipv4Addresses is always the union of the map, sorted numerically with each address once, and spec.ttl is the lowest TTL any contributor sets (none set means the zone's TTL). Scout rebuilds both from the map on every write, so editing them by hand is undone on the next reconcile. Do not edit the annotation: a record whose map cannot be parsed stops Scout from writing it until the annotation is fixed or removed.

Records written before ADR-0026 (one per resource, labelled source-kind, source-namespace and source-name) are replaced automatically: see the Migration Guide.

Several resources publishing one name¶

When two or more resources resolve to the same zone and DNS name, Scout publishes one record holding all of their addresses. For example, one kube-API LoadBalancer Service per availability zone, all at the apex:

apiVersion: v1
kind: Service
metadata:
  name: kube-api-a          # likewise kube-api-b (10.0.0.241), kube-api-c (10.0.0.240)
  namespace: kube-system
  annotations:
    bindy.firestoned.io/scout-enabled: "true"
    bindy.firestoned.io/zone: "cluster.example.com"
    bindy.firestoned.io/record-name: "@"
spec:
  type: LoadBalancer
status:
  loadBalancer:
    ingress:
      - ip: 10.0.0.246

Scout writes one ARecord, scout-<cluster>-apex-cluster-example-com-<hash>, with ipv4Addresses: [10.0.0.240, 10.0.0.241, 10.0.0.246], and BIND9 serves all three addresses for cluster.example.com.

Any kind, any namespace. An Ingress, a Service and an HTTPRoute that publish one name share the record, as do resources in different namespaces. Each resource is still checked on its own (zone authorization, --allowed-zones, --allowed-ip-ranges) before it adds its addresses, and Scout logs at info level when a resource joins a name others already publish.
Removing one resource removes only its addresses. Deleting kube-api-b, opting it out, or changing its record-name rewrites the record with the other two addresses. The record is deleted only when the last resource leaves the name.
Different TTLs publish the lowest. If the resources set different bindy.firestoned.io/ttl values, the record uses the lowest and Scout logs a warning.
Writes are atomic. Scout reads the record, changes only its own entry, rebuilds the full address list, and writes it back only if the record has not changed since it read it (otherwise it starts again). The operator then replaces the DNS answer in one update. No reconcile ever publishes a partial set.
One cluster only. Each Scout writes its own records (the record name includes the cluster name), so two clusters never merge into one record. See Two clusters publishing one name.

Two clusters publishing one name¶

When two edge clusters are registered for the same zone (ADR-0025) and both publish the same name, the cluster that published it first keeps it (ADR-0027). The other cluster's record writes nothing to BIND9 and shows the conflict:

$ kubectl get arecord scout-bar-api-shared-test-<hash> -n bindy-system \
    -o jsonpath='{.status.conditions[?(@.type=="Ready")]}'
{"type":"Ready","status":"False","reason":"RRsetConflict",
 "message":"ARecord bindy-system/scout-foo-api-shared-test-<hash> of cluster 'foo' has published 'api' in shared.test; ..."}

Who keeps the name is the record that has published it (its status.publishedName matches and it has written to BIND9). A record that fails a reconcile keeps the name; a record that never published cannot take it. If both published before this rule existed, the older record keeps it.
When the holder goes away (its source is deleted or opted out, or it stops publishing the name), the held-back record takes over on its own, with no timer.
Rebuilds follow the rule. When a BIND9 primary is wiped and its zones are replayed, held-back records are skipped, so the holder stays served.
Renames are not conflicts when both cluster names are registered to the same account (bindy bootstrap mc --cluster-name new,old, as in Renaming a registered cluster). A rename without that step shows RRsetConflict on the new records, with the old records still serving, until both names are registered.
Only Scout records. Two hand-written records that share a name, or a hand-written record next to a Scout one, behave as before.

Finding a resource's records¶

Select by the resource's contributor label:

LABEL="contributor.scout.bindy.firestoned.io/$(printf '%s\0%s\0%s' Service kube-system kube-api-a | sha256sum | cut -c1-16)"
kubectl get arecords -n bindy-system -l "${LABEL}"

or list a cluster's records and read the contributor annotation:

kubectl get arecords -n bindy-system \
  -l bindy.firestoned.io/managed-by=scout,bindy.firestoned.io/source-cluster=<cluster> \
  -o custom-columns='NAME:.spec.name,ADDRESSES:.spec.ipv4Addresses,CONTRIBUTORS:.metadata.annotations.bindy\.firestoned\.io/scout-contributors'

Record names¶

A Scout ARecord is named scout-{cluster}-{dns-name}-{zone}-{hash}:

scout-{cluster}-{dns-name}-{zone} is a readable prefix, with the apex (@) spelled apex, lowercased, with every character other than a-z, 0-9 and - replaced by -, and truncated (with any hyphen left at the cut removed) so the whole name fits the 253-character Kubernetes limit;
{hash} is the first 8 hex characters of the SHA-256 of cluster, zone and dns-name (the last two lowercased) joined by NUL bytes, so the name is unique to the DNS name even when the readable prefix is not (a.b and a-b, or the apex and a name called apex).

Every resource that publishes the same name in the same zone therefore writes the same record. The name is an implementation detail: the published DNS name comes from spec.name.

The zone label is particularly important: it lets you configure a DNSZone to automatically pull in all ARecords created by Scout for that zone:

apiVersion: bindy.firestoned.io/v1beta1
kind: DNSZone
metadata:
  name: example-com
spec:
  zoneName: example.com
  recordsFrom:
    - selector:
        matchLabels:
          bindy.firestoned.io/managed-by: scout
          bindy.firestoned.io/zone: example.com

Upgrading Scout¶

Run exactly one Scout per cluster, with the Deployment's strategy set to Recreate (as bindy bootstrap scout and deploy/scout/deployment.yaml do). Scout has no leader election: under the default RollingUpdate an upgrade runs the old and the new pod side by side, both publish, and a source that changes in that window can be published by the old version in a way the new one never revisits (for example a per-resource record next to the per-name record ADR-0026 introduced). Recreate stops the old pod first.

Scout drains on SIGTERM (no new reconcile starts, running ones finish, then it exits), so the gap with no Scout running is about a second. The first upgrade to a Scout that drains this way still waits out the old pod's 30-second grace period once. DNS keeps serving everything already published during the gap, and changes made to sources in it are published when the new pod starts, because it reconciles every source at startup. More than one replica is not supported for the same reason.

bindy bootstrap scout switches an existing Deployment to Recreate for you. If you manage the Scout Deployment yourself (Helm, Kustomize, GitOps), set strategy.type: Recreate there too. A client-side kubectl apply makes the switch on its own; a server-side apply is refused while the Deployment still has the rollingUpdate block the API server defaulted, so remove it first:

kubectl patch deployment bindy-scout -n bindy-system --type=merge \
  -p '{"spec":{"strategy":{"type":"Recreate","rollingUpdate":null}}}'

Configuration Reference¶

CLI Flags¶

Flag	Description
`--cluster-name <NAME>`	Required (unless env var set). Logical name of this cluster stamped on all created ARecord labels. Used to distinguish records created by different clusters writing to the same bindy namespace.
`--namespace <NS>`	Namespace where ARecords are created. Defaults to `bindy-system`.
`--default-zone <ZONE>`	Default DNS zone applied to all Ingresses and Services when no `bindy.firestoned.io/zone` annotation is present (e.g. `example.com`). When combined with `--default-ips`, resources only need `bindy.firestoned.io/scout-enabled: "true"`.
`--default-ips <IP[,IP]>`	Comma-separated default IP address(es) used when no per-resource `bindy.firestoned.io/ip` annotation or LoadBalancer status IP is available. Useful for shared-ingress topologies (e.g. Traefik).
`--gateway-service <class=target>`	Repeatable. Maps a `gatewayClass` to the LoadBalancer Service(s) backing it, used to resolve addresses for HTTPRoute/GRPCRoute/TLSRoute/TCPRoute via their `parentRefs` when a Gateway has no `status.addresses`. `target` is either `namespace/name` (one Service, e.g. `traefik=traefik/traefik`) or `namespace/<label-selector>` (every matching LoadBalancer Service, scoped to the route's Gateway by the GEP-1762 `gateway-name` label when present, e.g. `traefik=traefik/app.kubernetes.io/name=traefik,example.com/dns-vip=public`; equality-based selectors only). See Addresses from the Gateway. Multi-label selectors (with commas) must use this flag rather than the env var. The configured classes double as the allow-list of gateways Scout will follow.
`--remote-endpoint <URL>`	(Phase 3, ADR-0008) Bindy cluster API URL for the endpoint remote mode: a Linkerd-mirrored meshed proxy, a konnectivity endpoint, or the API server directly. Requires `--remote-token-file`. Mutually exclusive with `BINDY_SCOUT_REMOTE_SECRET` (startup error if both are set).
`--remote-token-file <PATH>`	(Phase 3) Path to a bearer-token file minted by the Bindy cluster (mounted Secret, CSI or external-secrets delivery). Re-read by kube-rs on rotation — no restart needed.
`--remote-ca-file <PATH>`	(Phase 3) Path to the remote endpoint's CA bundle (PEM). Optional: when unset, webpki public roots are used.
`--allowed-zones <ZONE[,ZONE]>`	Zones Scout may publish into, each with its subzones. Unset means every zone (with a startup warning). See Publishing limits.
`--allowed-ip-ranges <CIDR[,CIDR]>`	IPv4 ranges every published address must fall in. Unset means every address (with a startup warning).
`--namespace-selector <SELECTOR>`	A Kubernetes label selector (e.g. `bindy.firestoned.io/scout-enabled=true`) restricting which namespaces Scout will act in — same syntax as `kubectl get ns -l <selector>`. A namespace must match this selector and the individual Ingress/Service/route object must still carry its own opt-in annotation; both gates apply. Strongly recommended for every production deployment — see Namespace Whitelisting below.

CLI flags take precedence over the corresponding environment variables.

A misconfigured Scout fails at startup

Scout validates its whole configuration before it starts watching, and exits with an error naming the setting instead of running degraded:

a flag or environment variable that is set but empty (for example BINDY_SCOUT_DEFAULT_ZONE="" from a template that rendered to nothing): unset it or give it a value;
a malformed --gateway-service / BINDY_SCOUT_GATEWAY_SERVICES entry (one that is not class=namespace/name or class=namespace/<label-selector>); an empty entry from a trailing comma is still ignored;
a --default-ips / BINDY_SCOUT_DEFAULT_IPS entry that is not an IPv4 address;
an --allowed-zones entry that is * or not a DNS name, an --allowed-ip-ranges entry that is not an IPv4 address or CIDR range, a --default-zone outside the allowed zones, or a --default-ips entry outside the allowed ranges;
a missing cluster name, or an ambiguous or incomplete remote transport (see below).

Environment Variables¶

Variable	Default	Description
`BINDY_SCOUT_CLUSTER_NAME`	—	Required when `--cluster-name` is not set.
`BINDY_SCOUT_NAMESPACE`	`bindy-system`	Namespace where ARecords are created.
`POD_NAMESPACE`	`default`	Scout's own namespace. Always excluded from Ingress watching to prevent Scout from watching resources in its own namespace. Injected automatically by the Kubernetes downward API.
`BINDY_SCOUT_EXCLUDE_NAMESPACES`	—	Comma-separated list of additional namespaces to skip. Useful to exclude system namespaces (`kube-system`, `kube-public`, etc.) that will never have Scout-annotated Ingresses.
`BINDY_SCOUT_DEFAULT_ZONE`	—	Default DNS zone for all Ingresses and Services when no `bindy.firestoned.io/zone` annotation is present. Overridden by `--default-zone`. When set alongside `BINDY_SCOUT_DEFAULT_IPS`, resources only need `bindy.firestoned.io/scout-enabled: "true"`.
`BINDY_SCOUT_DEFAULT_IPS`	—	Comma-separated default IP address(es) used when no per-resource annotation override or LoadBalancer status IP is available. Useful for shared-ingress topologies (e.g. Traefik) where all resources resolve to the same VIP(s). Overridden by `--default-ips`.
`BINDY_SCOUT_GATEWAY_SERVICES`	unset	Comma-separated `gatewayClass=target` map for gateway-chain IP resolution on HTTPRoute/GRPCRoute/TLSRoute/TCPRoute, e.g. `traefik=traefik/traefik`. `target` is `namespace/name` (one Service) or `namespace/<label-selector>` (every matching LoadBalancer Service, see Addresses from the Gateway). Because commas separate entries here, multi-label selectors must use the repeatable `--gateway-service` flag. Overridden by `--gateway-service`.
`BINDY_SCOUT_NAMESPACE_SELECTOR`	— (every namespace eligible)	Label selector restricting which namespaces Scout will act in. Overridden by `--namespace-selector`. Unset means every namespace in the cluster is eligible — running without this set is not recommended for production. See Namespace Whitelisting.
`BINDY_SCOUT_ALLOWED_ZONES`	unset (every zone)	Comma-separated zones Scout may publish into, each with its subzones. Overridden by `--allowed-zones`.
`BINDY_SCOUT_ALLOWED_IP_RANGES`	unset (every address)	Comma-separated IPv4 CIDR ranges every published address must fall in. Overridden by `--allowed-ip-ranges`.
`BINDY_SCOUT_REMOTE_SECRET`	—	(Phase 2) Name of a Secret in the local cluster containing a `kubeconfig` key. When set, Scout targets the remote Bindy cluster for ARecord creation and zone validation. When unset, same-cluster mode is used.
`BINDY_SCOUT_REMOTE_SECRET_NAMESPACE`	Scout's own namespace	(Phase 2) Namespace of the `BINDY_SCOUT_REMOTE_SECRET`. Defaults to Scout's own namespace (`POD_NAMESPACE`).
`BINDY_SCOUT_REMOTE_ENDPOINT`	—	(Phase 3, ADR-0008) Bindy cluster API URL for the endpoint remote mode. Requires `BINDY_SCOUT_REMOTE_TOKEN_FILE`; mutually exclusive with `BINDY_SCOUT_REMOTE_SECRET`. Overridden by `--remote-endpoint`.
`BINDY_SCOUT_REMOTE_TOKEN_FILE`	—	(Phase 3) Path to a bearer-token file minted by the Bindy cluster; re-read on rotation. Overridden by `--remote-token-file`.
`BINDY_SCOUT_REMOTE_CA_FILE`	—	(Phase 3) Path to the endpoint's CA bundle (PEM); unset means webpki public roots. Overridden by `--remote-ca-file`.
`RUST_LOG`	`info`	Log level: `trace`, `debug`, `info`, `warn`, `error`.
`RUST_LOG_FORMAT`	`text`	Log format: `text` (compact, human-readable) or `json` (structured, for log aggregators).

Remote endpoint mode and Linkerd multicluster (Phase 3)¶

The kubeconfig Secret (Phase 2) bundles endpoint, CA and token into one blob. The endpoint mode (ADR-0008) splits them: the endpoint and CA live in the Deployment spec, and the credential is a bare token file — rotatable without restarting Scout, and deliverable by external-secrets or a mounted Secret.

env:
  - name: BINDY_SCOUT_REMOTE_ENDPOINT
    value: "https://bindy-api-mirror.linkerd-multicluster.svc.cluster.local:6443"
  - name: BINDY_SCOUT_REMOTE_TOKEN_FILE
    value: "/var/run/secrets/bindy-remote/token"
  - name: BINDY_SCOUT_REMOTE_CA_FILE
    value: "/var/run/secrets/bindy-remote/ca.crt"
volumeMounts:
  - name: bindy-remote-credentials
    mountPath: /var/run/secrets/bindy-remote
    readOnly: true
volumes:
  - name: bindy-remote-credentials
    secret:
      secretName: bindy-remote-token   # holds `token` + `ca.crt` keys

Two things Linkerd multicluster does not change:

The Kubernetes API server is not meshed — it runs no sidecar. To get Linkerd mTLS on the cross-cluster hop, mirror a meshed proxy in front of the Bindy cluster's API (e.g. a small kube-api-proxy Deployment in the mesh), and point BINDY_SCOUT_REMOTE_ENDPOINT at the mirrored Service.
Authentication is unchanged — whatever the transport, the Bindy cluster's API server must receive a credential it accepts. Use the same scoped ServiceAccount from deploy/scout/remote-cluster-rbac.yaml (arecords CRUD + dnszones read) and deliver its token to the workload cluster as the token file. Per ADR-0002's credential-direction principle, the credential always points at the Bindy cluster.

Same-cluster mode, the kubeconfig Secret, and the endpoint mode are mutually exclusive; Scout fails closed at startup on ambiguous combinations.

Full Deployment Example with All Variables¶

apiVersion: apps/v1
kind: Deployment
metadata:
  name: bindy-scout
  namespace: bindy-system
spec:
  replicas: 1
  strategy:
    type: Recreate
  selector:
    matchLabels:
      app.kubernetes.io/name: bindy
      app.kubernetes.io/component: scout
  template:
    metadata:
      labels:
        app.kubernetes.io/name: bindy
        app.kubernetes.io/component: scout
    spec:
      serviceAccountName: bindy-scout
      containers:
        - name: scout
          image: ghcr.io/firestoned/bindy:latest
          args:
            - scout
            # Alternatively: --cluster-name prod
          env:
            - name: BINDY_SCOUT_CLUSTER_NAME
              value: "prod"
            - name: BINDY_SCOUT_NAMESPACE
              value: "bindy-system"
            - name: POD_NAMESPACE
              valueFrom:
                fieldRef:
                  fieldPath: metadata.namespace
            - name: BINDY_SCOUT_EXCLUDE_NAMESPACES
              value: "kube-system,kube-public,kube-node-lease"
            - name: RUST_LOG
              value: "info"
            - name: RUST_LOG_FORMAT
              value: "json"
          resources:
            requests:
              cpu: "50m"
              memory: "64Mi"
            limits:
              cpu: "200m"
              memory: "128Mi"

RBAC Requirements¶

Scout requires cluster-wide watch access to Ingress and Service resources, read access to DNSZone and Namespace resources, and write access to ARecord resources in the target namespace. It requires no Secret access at all unless you use Phase 2 (multi-cluster) mode — see below.

Namespace access is low-sensitivity

The namespaces: get, list rule is namespace metadata only (names and labels, no Secret data) and is required for namespace whitelisting.

---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: bindy-scout
  namespace: bindy-system
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: bindy-scout
rules:
  # Watch and mutate Ingresses across all namespaces.
  # patch+update required because kube-rs finalizer patches the main resource.
  - apiGroups: ["networking.k8s.io"]
    resources: ["ingresses"]
    verbs: ["get", "list", "watch", "patch", "update"]
  - apiGroups: ["networking.k8s.io"]
    resources: ["ingresses/finalizers"]
    verbs: ["update"]
  # Watch LoadBalancer Services for external IP → ARecord automation.
  # patch+update required to add/remove the Scout finalizer on Service metadata.
  - apiGroups: [""]
    resources: ["services"]
    verbs: ["get", "list", "watch", "patch", "update"]
  - apiGroups: [""]
    resources: ["services/finalizers"]
    verbs: ["update"]
  # Watch HTTPRoutes/GRPCRoutes/TLSRoutes/TCPRoutes from the Gateway API and manage finalizers.
  # patch+update required to add/remove the Scout finalizer on route metadata.
  - apiGroups: ["gateway.networking.k8s.io"]
    resources: ["httproutes", "grpcroutes", "tlsroutes", "tcproutes"]
    verbs: ["get", "list", "watch", "patch", "update"]
  # route/finalizers subresource for forward-compatibility.
  - apiGroups: ["gateway.networking.k8s.io"]
    resources: ["httproutes/finalizers", "grpcroutes/finalizers", "tlsroutes/finalizers", "tcproutes/finalizers"]
    verbs: ["update"]
  # Gateways are read-only — Scout reads status.addresses to discover external IPs.
  - apiGroups: ["gateway.networking.k8s.io"]
    resources: ["gateways"]
    verbs: ["get", "list", "watch"]
  # Read DNSZones for zone validation
  - apiGroups: ["bindy.firestoned.io"]
    resources: ["dnszones"]
    verbs: ["get", "list", "watch"]
  # Read Namespace labels for --namespace-selector / BINDY_SCOUT_NAMESPACE_SELECTOR.
  # Low-sensitivity (name/labels only, no Secret data).
  - apiGroups: [""]
    resources: ["namespaces"]
    verbs: ["get", "list"]
  # NOTE: deliberately no Secret rule here. See "RBAC for Phase 2 (Multi-Cluster) Mode"
  # below for the namespaced, resourceNames-restricted Role used instead.
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: bindy-scout
subjects:
  - kind: ServiceAccount
    name: bindy-scout
    namespace: bindy-system
roleRef:
  kind: ClusterRole
  name: bindy-scout
  apiGroup: rbac.authorization.k8s.io
---
# Separate Role for writing ARecords in the target namespace
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  name: bindy-scout-writer
  namespace: bindy-system
rules:
  - apiGroups: ["bindy.firestoned.io"]
    resources: ["arecords"]
    verbs: ["get", "list", "watch", "create", "update", "patch", "delete"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: bindy-scout-writer
  namespace: bindy-system
subjects:
  - kind: ServiceAccount
    name: bindy-scout
    namespace: bindy-system
roleRef:
  kind: Role
  name: bindy-scout-writer
  apiGroup: rbac.authorization.k8s.io

RBAC for Phase 2 (Multi-Cluster) Mode¶

If — and only if — you run Scout with BINDY_SCOUT_REMOTE_SECRET set, Scout additionally needs to read that one kubeconfig Secret. This is granted by a separate, namespaced, resourceNames-restricted Role/RoleBinding — not a cluster-wide grant on the main bindy-scout ClusterRole. Apply this only if you use Phase 2 mode (deploy/scout/secrets-reader-rbac.yaml, or automatically via bindy bootstrap scout --remote-secret <name>):

apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  name: bindy-scout-secrets-reader
  namespace: bindy-system
rules:
  # resourceNames restricts this to exactly the one kubeconfig Secret — not every
  # Secret in this namespace, and not any Secret in any other namespace.
  - apiGroups: [""]
    resources: ["secrets"]
    resourceNames: ["bindy-scout-remote-kubeconfig"]
    verbs: ["get"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: bindy-scout-secrets-reader
  namespace: bindy-system
subjects:
  - kind: ServiceAccount
    name: bindy-scout
    namespace: bindy-system
roleRef:
  kind: Role
  name: bindy-scout-secrets-reader
  apiGroup: rbac.authorization.k8s.io

bindy bootstrap scout --remote-secret <name> provisions this automatically, with resourceNames set to the exact Secret name you passed. Same-cluster-only deployments (the default — no --remote-secret) get no Secret access whatsoever.

Gateway API Routes (HTTPRoute, GRPCRoute, TLSRoute, and TCPRoute)¶

In addition to watching Ingress resources, Scout also supports Gateway API routes: HTTPRoute, GRPCRoute, TLSRoute, and TCPRoute. These resources provide a more modern, flexible alternative to Ingress with better separation of concerns.

Scout treats HTTPRoute, GRPCRoute, TLSRoute, and TCPRoute similarly to Ingress:

Watches all HTTPRoute/GRPCRoute/TLSRoute/TCPRoute resources cluster-wide (excluding its own namespace), for each kind whose CRD is installed — kinds that are not served are detected at startup and skipped, see Gateway API detection
Requires the same bindy.firestoned.io/scout-enabled: "true" opt-in annotation
Uses the same annotation scheme for zone, IP, and TTL configuration
HTTPRoute / GRPCRoute / TLSRoute: publishes each hostname in spec.hostnames[], adding the route's addresses to that name's ARecord (one record per DNS name, shared with any other resource that publishes it; see Several resources publishing one name)
TCPRoute: has no spec.hostnames[] field, so it publishes the one name given by the bindy.firestoned.io/record-name annotation (required)

Why Use Gateway API Routes?¶

HTTPRoute: Provides advanced HTTP routing (path-based, method-based, header matching) without the Ingress resource limitations
GRPCRoute: Provides Gateway API routing for gRPC services. Scout creates DNS records for each declared hostname; it does not inspect gRPC service or method matches.
TLSRoute: For TLS-only traffic (non-HTTP protocols over TLS, gRPC, custom protocols), Scout ensures DNS records are created for all declared hostnames
TCPRoute: For TCP-based services such as databases, proxies, or other L4 traffic. TCPRoute has no spec.hostnames[] field, so the record name must be supplied via bindy.firestoned.io/record-name. Scout creates exactly one ARecord. The name is validated like every other record-name override: an invalid one (for example, one containing whitespace or a label starting with -) is logged as a warning and no record is created until it is fixed.

Quick Example: HTTPRoute¶

apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: api-gateway
  namespace: my-app
  annotations:
    bindy.firestoned.io/scout-enabled: "true"
    bindy.firestoned.io/zone: "example.com"
    bindy.firestoned.io/ip: "192.168.1.100"
spec:
  hostnames:
    - api.example.com
    - secure-api.example.com
  parentRefs:
    - name: my-gateway
      namespace: my-app
  rules:
    - backendRefs:
        - name: api-service
          port: 8080

Scout will publish two names, one ARecord each: - scout-{cluster}-api-example-com-{hash} for api.example.com - scout-{cluster}-secure-api-example-com-{hash} for secure-api.example.com

Quick Example: TLSRoute¶

apiVersion: gateway.networking.k8s.io/v1
kind: TLSRoute
metadata:
  name: grpc-gateway
  namespace: my-app
  annotations:
    bindy.firestoned.io/scout-enabled: "true"
    bindy.firestoned.io/zone: "example.com"
    bindy.firestoned.io/ip: "192.168.1.101"
spec:
  hostnames:
    - secure.example.com
    - grpc.example.com
  parentRefs:
    - name: my-gateway
      namespace: my-app
  rules:
    - backendRefs:
        - name: grpc-service
          port: 5051

Scout will publish two names, one ARecord each: - scout-{cluster}-secure-example-com-{hash} for secure.example.com - scout-{cluster}-grpc-example-com-{hash} for grpc.example.com

Quick Example: TCPRoute¶

apiVersion: gateway.networking.k8s.io/v1alpha2
kind: TCPRoute
metadata:
  name: db-gateway
  namespace: my-app
  annotations:
    bindy.firestoned.io/scout-enabled: "true"
    bindy.firestoned.io/zone: "example.com"
    bindy.firestoned.io/ip: "192.168.1.102"
    bindy.firestoned.io/record-name: "db"
spec:
  parentRefs:
    - name: my-gateway
      namespace: my-app
  rules:
    - backendRefs:
        - name: postgres
          port: 5432

Scout will create one ARecord for db.example.com.

Addresses from the Gateway¶

A route without a bindy.firestoned.io/ip annotation publishes the addresses of the Gateways its parentRefs name (ADR-0028):

A Gateway's own IPv4 status.addresses, when it has any.
Otherwise, when the Gateway's gatewayClassName is in --gateway-service, the external IPv4 addresses of the LoadBalancer Services the class's target names:
- namespace/name: that one Service;
- namespace/<label-selector>: every LoadBalancer Service in the namespace the selector matches, so a gateway that runs one Service per VIP publishes all of its VIPs. A Service that has no address yet, or is being deleted, adds nothing.
Otherwise, --default-ips.

A route with several parentRefs publishes the addresses of all of them.

Several Gateways of one class. Implementations that create one LoadBalancer Service per Gateway (Envoy Gateway, Cilium, Istio) label each of them gateway.networking.k8s.io/gateway-name: <gateway>, as Gateway API GEP-1762 requires. When any Service a selector matches carries that label, a route publishes only the matched Services labelled with its Gateway's name, never another Gateway's VIPs. When none carries it (one Service shared by every Gateway of the class, as with Traefik), every match counts. The label holds a name, not a namespace: keep a selector to Services whose Gateways have distinct names, or two same-named Gateways in different namespaces share each other's addresses.

Keep the selector to the VIPs you want published. A selector matches every LoadBalancer Service with those labels, including ones you did not mean to publish. The Traefik chart, for example, gives every Service it creates app.kubernetes.io/name: traefik, extra internal ones (service.additionalServices) included. Put a label of your own on exactly the public VIP Services and select on it:

# What the selector would publish today:
kubectl get svc -n traefik -l 'app.kubernetes.io/name=traefik,example.com/dns-vip=public' \
  -o custom-columns=NAME:.metadata.name,TYPE:.spec.type,IPS:.status.loadBalancer.ingress[*].ip

--gateway-service traefik=traefik/app.kubernetes.io/name=traefik,example.com/dns-vip=public

Selectors are equality-based: key=value, key==value, key!=value, key and !key, joined by commas. Set-based selectors (key in (a,b)) are refused at startup.

Re-resolution. Scout watches Gateways and Services, and a route re-resolves whenever one of its Gateways changes, or a Service its Gateway's class target matches is created, gets or loses an address, starts deleting, or is deleted. A VIP added to the gateway reaches DNS without touching the route, and a VIP removed leaves DNS. Both are read from Scout's watch caches; a route reconcile makes no API call to find its Gateway's addresses.

With --allowed-ip-ranges. A discovered Gateway or Service address outside the allowed ranges is dropped, with a warning naming the Gateway or Service, and the route publishes the rest (nothing, when nothing is left). An address the operator wrote (the bindy.firestoned.io/ip annotation, --default-ips) outside the ranges still stops the source publishing, as for every other kind. See Publishing limits.

Record Naming for Gateway Routes¶

Gateway API routes use spec.hostnames[] instead of spec.rules[].host. Each hostname publishes one DNS name, and each DNS name is one ARecord, named as described in Record names. The record is named after the DNS name, not the route, so an HTTPRoute, a GRPCRoute and a TLSRoute that publish the same hostname share one record (see Several resources publishing one name):

Hostname	Zone	Record CR name
`api.example.com` (HTTPRoute `api-gateway`)	`example.com`	`scout-prod-api-example-com-{hash}`
`secure-api.example.com` (HTTPRoute `api-gateway`)	`example.com`	`scout-prod-secure-api-example-com-{hash}`
`grpc-api.example.com` (GRPCRoute `grpc-api`)	`example.com`	`scout-prod-grpc-api-example-com-{hash}`
`grpc.example.com` (TLSRoute `grpc-gateway`)	`example.com`	`scout-prod-grpc-example-com-{hash}`

The record name within the zone is derived identically to Ingress rules:

Hostname	Zone	Derived record name
`api.example.com`	`api.example.com`	`@` (apex record)
`secure.api.example.com`	`api.example.com`	`secure`
`deep.sub.api.example.com`	`api.example.com`	`deep.sub`
`secure-api.example.com`	`api.example.com`	(skipped: not in zone)

Labels on Gateway Route ARecords¶

Records published from Gateway API routes carry the same labels and contributor annotation as every other Scout record (see Labels and annotations on created ARecords): managed-by, source-cluster, zone, and one contributor label per route. The zone label lets DNSZone.spec.recordsFrom label selectors discover the record.

This allows you to configure a DNSZone to pull in all ARecords created by Scout from both Ingress and Gateway API routes:

apiVersion: bindy.firestoned.io/v1beta1
kind: DNSZone
metadata:
  name: api-example-com
spec:
  zoneName: api.example.com
  recordsFrom:
    - selector:
        matchLabels:
          bindy.firestoned.io/managed-by: scout
          bindy.firestoned.io/zone: api.example.com

RBAC for Gateway API Routes¶

Scout requires read access (get, list, watch) to HTTPRoute, GRPCRoute, TLSRoute, TCPRoute, and Gateway resources. Gateway read access lets Scout follow a route's parentRefs to the serving gateway and discover its external IP. Add this rule to the Scout ClusterRole:

---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: bindy-scout
rules:
  # ... existing Ingress and Service rules ...

  # Watch HTTPRoutes/GRPCRoutes/TLSRoutes/TCPRoutes (Gateway API).
  # patch+update are required to add and remove the Scout finalizer on route
  # metadata — without them Scout cannot guarantee ARecord cleanup on deletion.
  - apiGroups: ["gateway.networking.k8s.io"]
    resources: ["httproutes", "grpcroutes", "tlsroutes", "tcproutes"]
    verbs: ["get", "list", "watch", "patch", "update"]
  # route/finalizers subresource for forward-compatibility.
  - apiGroups: ["gateway.networking.k8s.io"]
    resources: ["httproutes/finalizers", "grpcroutes/finalizers", "tlsroutes/finalizers", "tcproutes/finalizers"]
    verbs: ["update"]
  # Gateways ARE read-only — Scout reads status.addresses to discover external IPs.
  - apiGroups: ["gateway.networking.k8s.io"]
    resources: ["gateways"]
    verbs: ["get", "list", "watch"]

Scout watches Gateways cluster-wide (list, watch) when any route kind is served, and reads the LoadBalancer Services behind them from its existing cluster-wide Service watch, so gateway-chain IP resolution needs no permission beyond the rules above and Scout's services get/list/watch.

Note: Gateway objects are read-only for Scout: it only reads their status.addresses and gatewayClassName, and never mutates them.

Routes are not read-only. Scout adds and removes its own finalizer on the HTTPRoute / GRPCRoute / TLSRoute / TCPRoute objects it manages (add_finalizer_to_httproute and friends in crates/bindy-scout/src/scout.rs), which is why the ClusterRole above grants patch and update on route kinds. The finalizer is what lets Scout delete the corresponding ARecords before the route disappears; on a Phase-2 remote that is unreachable, it is released anyway after a 300s grace period so route deletion is never blocked. Scout does not modify any other field of a route.

Namespace Exclusions¶

Scout always excludes its own namespace (POD_NAMESPACE) from Ingress watching. This prevents:

Scout from watching its own Ingresses (if any) and creating circular references.
Unintended ARecords from platform Ingresses in the bindy namespace.

To exclude additional namespaces:

env:
  - name: BINDY_SCOUT_EXCLUDE_NAMESPACES
    value: "kube-system,kube-public,kube-node-lease,monitoring"

Namespace Whitelisting (`--namespace-selector`)¶

By default — with no --namespace-selector / BINDY_SCOUT_NAMESPACE_SELECTOR set — Scout is eligible to act in every namespace in the cluster, gated only by each source object's own opt-in annotation (bindy.firestoned.io/scout-enabled: "true", etc.) and the namespace exclusion list above. In other words: any tenant in any namespace can cause Scout to create an ARecord, simply by annotating their own Ingress/Service/route object.

Running with no namespace selector configured is not recommended. Set one:

env:
  - name: BINDY_SCOUT_NAMESPACE_SELECTOR
    value: "bindy.firestoned.io/scout-enabled=true"

or via the CLI flag: --namespace-selector "bindy.firestoned.io/scout-enabled=true".

Once set, Scout checks this selector against the namespace's own labels (not the resource's annotations) before acting on anything inside it — a genuine two-factor opt-in: the namespace must carry the label and the individual resource must carry its annotation. Label the namespaces you want Scout active in:

kubectl label namespace team-web bindy.firestoned.io/scout-enabled=true

Any selector expression accepted by kubectl get ns -l <selector> works — this is not limited to the single-label example above (e.g. environment in (staging,prod) is equally valid).

What changes when a namespace is unlabeled¶

If a namespace stops matching the selector (label removed, or the selector is newly introduced on an existing deployment), Scout treats every source object in that namespace exactly as if its opt-in annotation had been removed: any ARecords it created are deleted and its finalizer is released, unblocking normal object deletion. This means introducing --namespace-selector on an existing Scout deployment is a behavior change — any namespace not labeled at the time will have its Scout-managed ARecords cleaned up. Label every namespace that should keep working before rolling out the selector, not after.

Deletion and remote-cluster failures¶

When an opted-in Ingress/Service/route is deleted, Scout first deletes the ARecords it created (on the remote Bindy cluster in Phase 2 mode) and then releases its finalizer. If that remote cleanup fails — a broken or expired Phase 2 kubeconfig, or a remote-cluster outage — Scout retries for a grace period (5 minutes) and, past it, releases the finalizer anyway rather than hold the source object in Terminating. This prevents a single unreachable remote from blocking deletion of tenant objects cluster-wide. When the grace period is exceeded, Scout logs an error noting that the remote ARecords may be orphaned and must be reconciled separately (they are otherwise reaped by Scout's label-based stale-record cleanup once the remote is reachable again).

What this does and does not reduce¶

Setting a namespace selector meaningfully shrinks Scout's day-to-day operating footprint and requires a platform-level action (labeling a namespace) before any tenant's opt-in annotation takes effect — a real, valuable second gate. It does not by itself shrink the ClusterRole's RBAC ceiling: bindy-scout still holds cluster-wide patch/update on Ingress/Service/route types, so a directly compromised ServiceAccount token could still, in principle, act outside the labeled namespaces for those types. (As of 2026-07-19, Scout's Secret access is no longer part of this ceiling at all — the former cluster-wide secrets: get grant was replaced with a namespaced, resourceNames-restricted Role scoped to the single Phase 2 kubeconfig Secret; see RBAC for Phase 2 Mode above.) See docs/src/security/threat-model.md for the full analysis.

Multi-Cluster Mode¶

In many platform engineering setups, the DNS operator lives on a dedicated infrastructure cluster — isolated from workload traffic, hardened, and controlled by the platform team. Application workloads run on separate clusters that have no direct RBAC access to the DNS cluster. Scout bridges this gap without requiring network tunnels or federated identity.

The Queen Bee and Her Scouts¶

Think of the architecture using the same honeybee metaphor:

The Queen Bee is the central Bindy operator running on the dedicated Queen Bee cluster. She manages all DNS infrastructure — DNSZone CRs, ARecord CRs, and the BIND9 instances that serve DNS.
Scout Bees run on each workload cluster. They watch local Ingress resources and fly their discoveries back to the Queen, depositing ARecord CRs directly into her hive.

Application teams annotate their Ingresses as normal. They never need to know a separate DNS cluster exists.

graph LR subgraph queen["🐝 Queen Bee — DNS Cluster"] QB[Bindy Operator] ARecord["ARecord CRs\n(bindy-system)"] BIND9[BIND9 DNS Server] QB -->|reconciles| ARecord ARecord -->|programs via RNDC| BIND9 end subgraph child1["🌸 Child Cluster A"] Scout1["Scout Bee"] Ingress1["Ingress resources"] Secret1["remote-kubeconfig\nSecret"] Ingress1 -->|watch event| Scout1 Scout1 --- Secret1 end subgraph child2["🌸 Child Cluster B"] Scout2["Scout Bee"] Ingress2["Ingress resources"] Secret2["remote-kubeconfig\nSecret"] Ingress2 -->|watch event| Scout2 Scout2 --- Secret2 end subgraph child3["🌸 Child Cluster C"] Scout3["Scout Bee"] Ingress3["Ingress resources"] Secret3["remote-kubeconfig\nSecret"] Ingress3 -->|watch event| Scout3 Scout3 --- Secret3 end Scout1 -->|"server-side apply ARecord\n(via queen kubeconfig)"| ARecord Scout2 -->|"server-side apply ARecord\n(via queen kubeconfig)"| ARecord Scout3 -->|"server-side apply ARecord\n(via queen kubeconfig)"| ARecord

Each Scout authenticates to the Queen Bee cluster using a dedicated service account kubeconfig stored as a Secret in its own cluster. A Scout on Cluster A cannot impersonate or interfere with the Scout on Cluster B — each has its own independently revocable credentials.

How the Multi-Cluster Connection Works¶

sequenceDiagram participant Ops as Platform Engineer participant Queen as Queen Bee Cluster participant Child as Child Cluster Ops->>Queen: bindy bootstrap mc --service-account bindy-scout-remote Queen->>Queen: Create SA + Role (ARecord CRUD, DNSZone read) Queen->>Queen: Create SA token Secret, wait for token Queen->>Queen: Build kubeconfig for SA Queen-->>Ops: Outputs remote-kubeconfig Secret YAML (stdout) Ops->>Child: kubectl apply -f - (pipe or file) Child->>Child: Store Secret as bindy.firestoned.io/remote-kubeconfig Note over Child: Scout Deployment uses BINDY_SCOUT_REMOTE_SECRET Child->>Child: Ingress annotated with scout-enabled: "true" Child->>Child: Scout watches Ingress event Child->>Queen: Scout applies ARecord via kubeconfig from Secret Queen->>Queen: ARecord reconciler programs BIND9

Setup Guide¶

1. Bootstrap credentials on the Queen Bee cluster¶

Run bindy bootstrap mc against the Queen Bee cluster (the cluster running the Bindy operator). It creates a dedicated service account, the minimal RBAC Role and RoleBinding, waits for the SA token, and writes a bindy.firestoned.io/remote-kubeconfig Secret as YAML to a file readable only by you (mode 0600), because the Secret carries the service account token:

# Run against the Queen Bee cluster; writes ./bindy-scout-remote-kubeconfig.yaml
bindy bootstrap mc \
  --service-account bindy-scout-remote \
  --namespace bindy-system \
  --cluster-name foo \
  --allowed-zones foo.example.com

--cluster-name and --allowed-zones (given together) register the account for that cluster name and those zones; see Binding each cluster to its names and zones. Without them the account is created unregistered, and the command says so.

Expected output (stderr, progress only):

✓ Applied ServiceAccount bindy-scout-remote
✓ Applied Role bindy-scout-remote
✓ Applied RoleBinding bindy-scout-remote
✓ Applied SA token Secret bindy-scout-remote-token
⏳ Waiting for SA token to be populated...
✓ SA token ready

✓ Wrote the kubeconfig Secret to bindy-scout-remote-kubeconfig.yaml (mode 0600; it holds the token)
Apply it to each child cluster, then delete it:
    kubectl --context=<child-cluster> apply -f bindy-scout-remote-kubeconfig.yaml
    rm bindy-scout-remote-kubeconfig.yaml
Then set BINDY_SCOUT_REMOTE_SECRET=bindy-scout-remote-kubeconfig on the scout Deployment.

The file holds a Secret of type bindy.firestoned.io/remote-kubeconfig with a kubeconfig key containing the Queen Bee cluster credentials. Choose another path with --output <path> (-o). An existing file is restricted to 0600 before it is overwritten.

Use the default service account name

The default --service-account is bindy-scout-remote, which matches the RBAC manifests in deploy/scout/remote-cluster-rbac.yaml. Use a unique SA name per child cluster if you want independent credential revocation.

2. Apply the kubeconfig Secret to each child cluster¶

Per-child-cluster (recommended)One SA for several clusters

export KUBECONFIG=~/.kube/queen-bee.yaml

# Cluster A gets its own SA on the Queen Bee cluster
bindy bootstrap mc --service-account bindy-scout-remote-cluster-a -o cluster-a.yaml
kubectl --context=child-cluster-a apply -f cluster-a.yaml && rm cluster-a.yaml

# Cluster B gets its own SA
bindy bootstrap mc --service-account bindy-scout-remote-cluster-b -o cluster-b.yaml
kubectl --context=child-cluster-b apply -f cluster-b.yaml && rm cluster-b.yaml

export KUBECONFIG=~/.kube/queen-bee.yaml
bindy bootstrap mc -o scout-kubeconfig.yaml

kubectl --context=child-cluster-a apply -f scout-kubeconfig.yaml
kubectl --context=child-cluster-b apply -f scout-kubeconfig.yaml
rm scout-kubeconfig.yaml
# Each cluster uses the same credentials (same SA on the Queen Bee cluster);
# use a unique --service-account per child cluster for independent revocation

The Secret is never printed to stdout: --output - is refused, so the token cannot end up in terminal scrollback, a CI log or a session recording.

3. Configure Scout on the child cluster¶

Set two environment variables on the Scout Deployment to activate remote mode:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: bindy-scout
  namespace: bindy-system
spec:
  template:
    spec:
      containers:
        - name: scout
          image: ghcr.io/firestoned/bindy:latest
          args: ["scout", "--cluster-name", "cluster-a"]
          env:
            - name: BINDY_SCOUT_CLUSTER_NAME
              value: "cluster-a"
            - name: BINDY_SCOUT_NAMESPACE
              value: "bindy-system"
            - name: POD_NAMESPACE
              valueFrom:
                fieldRef:
                  fieldPath: metadata.namespace
            # --- Multi-cluster mode ---
            - name: BINDY_SCOUT_REMOTE_SECRET
              value: "bindy-scout-remote-kubeconfig"
            # Optional: if the Secret is in a different namespace than Scout
            # - name: BINDY_SCOUT_REMOTE_SECRET_NAMESPACE
            #   value: "bindy-system"
            - name: RUST_LOG
              value: "info"

When BINDY_SCOUT_REMOTE_SECRET is set, Scout loads the kubeconfig from that Secret and uses it for all ARecord creation and DNSZone validation — the Queen Bee cluster, not the local cluster.

Also grant RBAC to read this Secret

Setting the env var alone is not enough — Scout's ClusterRole grants no Secret access at all (see RBAC for Phase 2 Mode). Apply the namespaced secrets-reader Role too, with resourceNames matching the Secret name above:

kubectl --context=child-cluster-a apply -f deploy/scout/secrets-reader-rbac.yaml

or, if you manage Scout via bindy bootstrap scout, re-run it with --remote-secret bindy-scout-remote-kubeconfig to provision this automatically. Without it, Scout will fail to read the Secret with an RBAC-forbidden error.

4. Verify the connection¶

# Check Scout is running on the child cluster
kubectl --context=child-cluster-a get pods -n bindy-system -l app.kubernetes.io/component=scout

# Watch Scout logs — should see "remote mode" startup message
kubectl --context=child-cluster-a logs -n bindy-system -l app.kubernetes.io/component=scout -f

# Annotate an Ingress on the child cluster
kubectl --context=child-cluster-a annotate ingress my-app \
  bindy.firestoned.io/scout-enabled=true \
  bindy.firestoned.io/zone=example.com \
  -n my-app-ns

# Verify the ARecord was created on the Queen Bee cluster
kubectl --context=queen-bee get arecords -n bindy-system -l bindy.firestoned.io/source-cluster=cluster-a

RBAC: What `bootstrap mc` Creates¶

bindy bootstrap mc creates three resources on the Queen Bee cluster, all named after the service account:

Resource	Kind	Permissions
`bindy-scout-remote`	`ServiceAccount`	—
`bindy-scout-remote`	`Role`	`arecords`: get, list, watch, create, update, patch, delete
`bindy-scout-remote`	`Role`	`dnszones`: get, list, watch (for zone validation)
`bindy-scout-remote`	`RoleBinding`	Binds the Role to the SA
`bindy-scout-sources`	`ConfigMap`	Only with `--cluster-name` and `--allowed-zones`: the keys `bindy-scout-remote.clusters` and `bindy-scout-remote.zones` (shared ConfigMap, one pair of keys per account)

The Role is namespace-scoped (defaults to bindy-system). Scout cannot read or modify any other namespace on the Queen Bee cluster. It cannot read Secrets, access Pods, or perform any cluster-wide operations.

A separate ServiceAccount-type token Secret (bindy-scout-remote-token) is created with the kubernetes.io/service-account.name annotation so the Kubernetes token controller populates a long-lived token. The token is embedded in the output kubeconfig.

One SA per child cluster (recommended)

Using a unique service account per child cluster (--service-account bindy-scout-remote-cluster-a) allows you to revoke access for one cluster by simply deleting its SA on the Queen Bee cluster, without affecting other clusters.

Binding each cluster to its names and zones¶

Scout's own checks run on the child cluster. On the bindy cluster, a ServiceAccount token from bootstrap mc can write any ARecord in its namespace, so a compromised Scout could publish into another cluster's zone, stamp another cluster's name, or delete its records. Three controls on the bindy cluster close that (ADR-0025):

Registry. bindy bootstrap mc --cluster-name foo --allowed-zones foo.example.com writes two keys for the account into the bindy-scout-sources ConfigMap of the namespace the records go to:
```
apiVersion: v1
kind: ConfigMap
metadata:
  name: bindy-scout-sources
  namespace: bindy-system
data:
  bindy-scout-remote.clusters: "foo"
  bindy-scout-remote.zones: "foo.example.com"
```
Each account's keys are written under a field manager of its own, so registering one cluster never rewrites another's, and bindy bootstrap mc --revoke removes only that account's keys.
Admission policy. bindy-scout-source-binding (deploy/admission-policies/21-* and 22-*, installed by make admission-policies-install) refuses an ARecord create, update or delete by a registered account unless the record carries bindy.firestoned.io/managed-by: scout, one of the account's cluster names in source-cluster, and an allowed zone in zone. For an update or delete the existing record is checked too, so an account can neither rewrite nor delete another cluster's record. Unregistered principals (the operator, people, accounts created before this registry existed) are not affected, and neither is a namespace with no bindy-scout-sources ConfigMap.
Zone label. A DNSZone takes a record labelled bindy.firestoned.io/managed-by: scout only when the record's bindy.firestoned.io/zone label equals the zone's spec.zoneName (ignoring case and a trailing dot), whatever its recordsFrom selector says. A selector that matches only managed-by: scout can therefore not pick up another cluster's records.

Register existing accounts

Upgrading an existing installation? Follow Migrating to Scout Source Guardrails. An account minted before this registry existed is unconstrained until it is registered. Re-run bindy bootstrap mc with the same --service-account plus --cluster-name and --allowed-zones (it re-applies the same ServiceAccount and RBAC), or add its two keys to the ConfigMap by hand.

What this does not cover

Two clusters registered for the same zone may still publish the same name, and the last record written wins. Do not register a zone for more than one cluster unless they deliberately share it. The registry ConfigMap is writable by whoever can write ConfigMaps in that namespace; Scout's own Role does not allow it.

Multi-Cluster Configuration Reference¶

Variable	Default	Description
`BINDY_SCOUT_REMOTE_SECRET`	—	Name of a Secret in the child cluster containing a `kubeconfig` key. When set, Scout uses that kubeconfig to create `ARecord` CRs and validate `DNSZone` resources on the Queen Bee cluster instead of the local cluster.
`BINDY_SCOUT_REMOTE_SECRET_NAMESPACE`	Scout's own namespace (`POD_NAMESPACE`)	Namespace where the remote kubeconfig Secret lives. Only set this if the Secret is in a different namespace than Scout itself.

Changing the Cluster Name¶

If you restart Scout with a different --cluster-name (or BINDY_SCOUT_CLUSTER_NAME), Scout automatically cleans up any ARecord CRs that were created by the old cluster name.

How It Works¶

ARecord CRs created by Scout carry bindy.firestoned.io/source-cluster and bindy.firestoned.io/zone labels identifying the cluster that created them and the DNS zone they publish into, and one contributor label per resource that publishes the name. The CR name also embeds the cluster name (e.g., scout-<cluster>-<dns-name>-<zone>-<hash>).

When Scout reconciles a resource under a new cluster name: 1. It writes the resource's addresses to the records of the new cluster name. 2. It selects the records whose source-cluster label does not match the current cluster name, whose zone label matches the resource's currently resolved zone, and that carry the resource's contributor label. Per-resource records from before ADR-0026, with the resource's kind, namespace and name labels (or no kind label, from before ADR-0022), are matched the same way. 3. Once the new records are served, it removes the resource's addresses from those stale records (deleting each record when no other resource is left on it) and deletes the per-resource ones.

The zone match matters: two entirely unrelated clusters can happen to run an Ingress with the same namespace + name (e.g. both deploy team-checkout/web-frontend) while publishing into different DNS zones. Without scoping by zone, each cluster's cleanup would treat the other's live ARecord as "stale" purely because the source-cluster label differs — and delete it, over and over, on every reconcile. Scoping by zone protects clusters publishing into distinct zones from this.

This does not protect clusters that share a zone. If several clusters publish into the same DNS zone (a normal multi-cluster-DNS topology) and happen to run resources of the same kind with the same namespace + name, they still match each other's selector and will mutually delete each other's live ARecords in a flapping loop. Give such resources distinct namespaces, names, or zones to avoid this; fully identifying "this same physical Scout instance under a prior cluster name" would need an instance-level marker that this mechanism does not provide. When each cluster's account is registered, the bindy cluster refuses those deletes instead: Scout logs the refusal and leaves the other cluster's record alone.

Renaming a registered cluster. The registry lists the names an account may stamp, so add the new name first (bindy bootstrap mc --cluster-name new,old ...), restart Scout with --cluster-name new and let it clean up, then re-run with --cluster-name new alone. If the old name is dropped first, the bindy cluster refuses the cleanup of the old records; Scout logs it and does not retry, and the old records must be deleted by hand. Registering both names is also what tells the operator the old and new records are one cluster, not two clusters claiming the same names (ADR-0027); without it, the new records are held back with RRsetConflict while the old ones keep serving.

This happens on every reconcile, so all stale records for the reconcile path are cleaned up on the next controller loop after the restart — no manual intervention required there.

On the delete and opt-out paths the zone is not taken from annotations alone. Opting out is documented as removing the bindy.firestoned.io/* annotations, and stripping them all in one edit removes the zone along with the opt-in — so by the time cleanup runs there may be no annotation left to read. Scout therefore cleans up every zone in the union of:

the zone resolved from the resource's annotations (or BINDY_SCOUT_DEFAULT_ZONE), if there still is one; and
the zone labels of the ARecords it just removed the resource from, which Scout wrote itself and which survive the annotation edit.

The labels also cover a BINDY_SCOUT_DEFAULT_ZONE that changed after the records were written, where the resolved zone no longer matches what is actually on disk.

Only if neither source yields a usable zone does Scout skip the stale-cluster step. It then logs a warning and lists (without deleting) any candidate stale ARecords left behind under a previous cluster name, before removing the resource from its own ARecords and removing its finalizer. Because the resource is gone, there is no future reconcile to retry that skipped cleanup: it is permanent unless an operator acts on the logged candidates.

Zones that cannot be used as a label value¶

Scout stamps the resolved zone onto every ARecord as the bindy.firestoned.io/zone label, and matches on that same label when cleaning up. A zone must therefore be a legal Kubernetes label value: at most 63 characters, starting and ending with an alphanumeric character, containing only -, _ and . in between.

A DNSZone's zoneName is validated per DNS label, not in total, so an ordinary internal zone can pass admission and still be too long overall:

payments-gateway.team-checkout.production.eu-west-1.example.internal   # 68 characters

A trailing dot (example.com.) is likewise a legal DNS name but not a legal label value, though the DNSZone CRD's zoneName pattern already rejects that one at admission.

When the resolved zone is not a usable label value, Scout logs a warning naming the zone and skips the resource entirely rather than attempting work that cannot succeed — creating the ARecord would fail with a 422, and the stale-cleanup query would fail with a 400. Shorten the zone name, or set a shorter bindy.firestoned.io/zone annotation on the resource.

Example¶

# Scout was previously running with --cluster-name prod-a
# Rename the cluster:
kubectl set env deployment/bindy-scout BINDY_SCOUT_CLUSTER_NAME=prod-b -n bindy-system

# After the rollout, Scout logs will show:
# Deleted stale ARecord after cluster-name change
#   arecord=scout-prod-a-default-my-app-<hash>-0
#   old_cluster=prod-a  new_cluster=prod-b

One cluster name per scout instance

All scouts writing to the same Queen Bee namespace must use unique cluster names. Duplicate cluster names cause one scout to overwrite the other's records.

Roadmap¶

Feature	Status	Roadmap
Same-cluster mode	✅ Complete	roadmap 12
Finalizer on Ingress	✅ Complete	roadmap 12
Remote cluster mode (kubeconfig Secret)	✅ Complete	roadmap 12
Remote endpoint mode (token file; Linkerd-compatible)	✅ Complete	roadmap 12, ADR-0008
LoadBalancer Service → ARecord	✅ Complete	roadmap 12
Namespace whitelisting via label selectors	✅ Complete (`--namespace-selector`, #437); Namespace watch pending	roadmap 13
SRV records from Service ports and Ingress	🔲 Planned	roadmap 14
Scout metrics, conflict detection, AAAA	🔲 Planned	roadmap 27

Bindy Scout¶

The Scout Bee¶

What Scout Solves¶

How It Works¶

Quick Start¶

1. Annotate your Ingress or Service¶

2. Deploy Scout¶

Annotations Reference¶

Zone authorization (cross-namespace)¶

Publishing limits for this cluster (--allowed-zones, --allowed-ip-ranges)¶

Watched Resources¶

1. Ingresses (Legacy)¶

2. Services (LoadBalancer)¶

3. Gateway API (HTTPRoute, GRPCRoute, TLSRoute, and TCPRoute)¶

Labels and annotations on created ARecords¶

Several resources publishing one name¶

Two clusters publishing one name¶

Finding a resource's records¶

Record names¶

Upgrading Scout¶

Configuration Reference¶

CLI Flags¶

Environment Variables¶

Remote endpoint mode and Linkerd multicluster (Phase 3)¶

Full Deployment Example with All Variables¶

RBAC Requirements¶

RBAC for Phase 2 (Multi-Cluster) Mode¶

Gateway API Routes (HTTPRoute, GRPCRoute, TLSRoute, and TCPRoute)¶

Why Use Gateway API Routes?¶

Quick Example: HTTPRoute¶

Quick Example: TLSRoute¶

Quick Example: TCPRoute¶

Addresses from the Gateway¶

Record Naming for Gateway Routes¶

Labels on Gateway Route ARecords¶

RBAC for Gateway API Routes¶

Namespace Exclusions¶

Namespace Whitelisting (--namespace-selector)¶

What changes when a namespace is unlabeled¶

Deletion and remote-cluster failures¶

What this does and does not reduce¶

Multi-Cluster Mode¶

The Queen Bee and Her Scouts¶

How the Multi-Cluster Connection Works¶

Setup Guide¶

1. Bootstrap credentials on the Queen Bee cluster¶

2. Apply the kubeconfig Secret to each child cluster¶

3. Configure Scout on the child cluster¶

4. Verify the connection¶

RBAC: What bootstrap mc Creates¶

Binding each cluster to its names and zones¶

Multi-Cluster Configuration Reference¶

Changing the Cluster Name¶

How It Works¶

Zones that cannot be used as a label value¶

Example¶

Roadmap¶

Publishing limits for this cluster (`--allowed-zones`, `--allowed-ip-ranges`)¶

Namespace Whitelisting (`--namespace-selector`)¶

RBAC: What `bootstrap mc` Creates¶
